R. STAHL
Explosion-Proof Electrical Products for Industrial and Hazardous Area Safety
Globally renowned, R. STAHL manufactures switchgear, automation, lighting and system solutions across multiple industrial and hazardous area market sectors. MacLean Electrical is an authorised stockist and distributor representing R. STAHL lighting products, control stations, junction boxes, plugs, sockets and accessories from our locations in the UK.
Browse MacLean International Group Technical Library
Browse our technical library for product details, specifications and images. If you can't find what you're looking for, don't hesitate to call us for a chat! In our technical library, you'll also find an enquiry basket. Simply add the products you're interested in to the basket, fill out the form and we'll promptly send you a quote.
Linear LED Lighting
Efficient and robust explosion-proof LED lighting, R. STAHL's LED luminaries are used in a range of industrial hazardous locations.
Key features of R. STAHL's explosion-proof lighting and LED luminaires:
- Easy to maintain with electronic ballast fitted to the reflector plate
- All-phase safety switch (Zone 1) and through wiring included as standard
- New sealing system and improved central lock for protection rating IP66 / IP67
- Extremely robust LED lights, with an impact strength rating of IK10, but lightweight at between 5 and 9 kg
LED EXLUX Series
Utilising the latest LED technology with an extremely high luminous efficacy, long service life and robust enclosures, the EXLUX series of luminaires is ideally suited to lighting surfaces at a mounting height of up to 10 m and can be used to illuminate both inside and outside areas. Optionally, the luminaire can be equipped with addressable equipment, which can be used to control and monitor the luminaire for the common battery systems.
EXLUX Series Linear LED Luminaires
Product Features
- ATEX and IECEx approved
- IP66/IP67 rated
- Luminous flux after 100,000 h still 90% of the starting luminous flux
- Optionally with DALI for controlling and monitoring the luminaire
- Optionally addressable for direct actuation of a common battery system
EXLUX Series 6002/4
- Zone 1 and Zone 21 hazardous areas
- Can be mounted on poles with pole mounting sleeve accessory
EXLUX Series 6402/4
- Zone 2 and Zone 22 hazardous areas
EXLUX Series Emergency LED Luminaires
Product Features
- ATEX and IECEx approved
- IP66/IP67 rated
- Can be adjusted from a 1.5 to a 3.0 h rated operating time
- Luminous flux after 100,000 h still 90% of the starting luminous flux
- Optionally with DALI for controlling and monitoring the light fitting
- Automatic weekly functional test and annual rated operating time test
EXLUX Series 6009/4
- Zone 1 and Zone 21 hazardous areas
EXLUX Series 6409/4
- Zone 2 and Zone 22 hazardous areas
Ex e Control Stations
Providing a wide scope of flexibility and options to suit different customer requirements, all R. STAHL Ex e control stations can be specially adapted to the intended purpose – choose not only the enclosure material, size and height, but also how it is equipped, and which devices are installed internally.
- Enclosure material: glass-fibre-reinforced polyester resin (GRP) or stainless steel
- Large selection of control station components: snap-mounted devices such as indicator lamps, control switches, ammeters, etc.
- Accessories available: flanges, cover hinges, etc.
- Individual control stations can be combined to form larger units
Series 8040/8150 Ex e Control Stations
Ex e control stations from R. STAHL are available in three sizes with a combinable, modular design offering flexibility - one standard version and customised variants.
Product Features
- Available in glass-fibre-reinforced polyester resin (GRP) and stainless steel, suitable for the marine industry and offshore applications
- Flexible: modular design and multiple sizes, with customer-specific versions possible
- ATEX, IECEx, ULB, NEPSI, UL, PESO, KGS, ITRI, UL approved
- -60 °C ... +40 °C (T6)
- -60 °C ... +55 °C (T5)
- IP66 rated
- Full assembly capabilities from MacLean Electrical – visit our Workshop page for more information on assembled enclosures: MacLean Approved Workshops
Junction and Terminal Boxes
R. STAHL junction and terminal boxes are available as standard or customised units and certified for use globally. From GRP to stainless steel, cast aluminium, high current and industrial versions, R. STAHL has a wide range of junction and terminal boxes for safe installation and use in harsh and hazardous areas.
The junction and terminal box range includes 8 product series:
- Junction box Series 8102
- Junction box Series 8118
- Terminal box Series 8118
- Terminal box Series 8118 with WAGO 221 Ex Connection terminal
- Ex e terminal box Series 8146/1
- Ex e terminal box NEC/IEC Series 8146/2
- Ex i terminal box Series 8146/2
- Ex i terminal box NEC/IEC Series 8146/2
Series 8146/8150 Ex e Terminal Boxes
Product Features
- Available in glass-fibre-reinforced polyester resin (GRP) and stainless steel, suitable for the marine industry and offshore applications
- Multiple box sizes with variable heights
- Suited to terminals up to 300 mm2 maximum
- ATEX, IECEx, ULB, NEPSI, UL, PESO, KGS, ITRI, UL approved
- -60 °C ... +40 °C (T6)
- -60 °C ... +55 °C (T5)
- Optional: flanges, cover hinges, flange enclosures, brass plates, metal cable glands
- IP66 rated
- Full assembly capabilities from MacLean Electrical – visit our Workshop page for more information on assembled enclosures: MacLean Approved Workshops
Plugs, Sockets and Couplers
Series 8570, 8571, 8572, 8573, 8579, 8580, 8581
Versatile and safe, the R. STAHL range of plugs, sockets and couplers are suitable for all international wiring, quick and easy to install and suited to operations in Zones 1, 2, 21 and 22. The following product categories are available from MacLean Electrical:
- Wall-mounting sockets
- Flange sockets
- Plugs
- Coupler sockets
- Cable reel
Product Features
- Self-cleaning contacts
- Compact size, allowing flange socket to be integrated into almost all enclosures (Series 8570/15)
- Load disconnect switch with mechanical locking for additional safety
- Operational in wide temperature range
- High impact and shock resistance
- Protection from liquid and dust ingress
- Floating pins ensure easy plugging and unplugging
- Coupler sockets with switch socket to connect both portable and fixed equipment, in addition to cables and circuits
- Stainless steel carrying frame and large carrying handle
- Free-standing set-up on feet where required
R. STAHL Tranberg
Tranberg IMT Circle & H System
Product Features
- Suitable for ATEX & IECEx Zone 1 areas
- Clearly indicates the TD/PM Circle and H
- Can be installed as stand-alone or fully integrated lighting and status light safety system
- Unique interlocking design withstands sheer force impact
- Robust design and durable to withstand harsh environments
- Multiple mounting alternatives and cable routing options offer flexible and prompt installation
- Suited for installations worldwide
- Minimum maintenance requirements
- CAP 437 certified
Helideck Status Lights
Status lighting is required where it may be hazardous for the helicopter and occupants to land on an installation.
Product Features
- Suited to Zone 1, Zone 2 and Safe Zone areas
- Main and repeater options
- Repeater lighting offers 360° visibility for helicopter pilots
- Automatic monitoring of all lighting units possible when used in combination with Tranberg Control System
- LED light source
- Powder coated seawater resistant aluminium
- Maintenance-free
- Night vision goggle (NVG) compatible
- Low power consumption: 30W main light and 3.5W repeater lights
- Operating temperature: -40 °C … +55 °C
- IECEx & ATEX approved
Helideck Perimeter Lights
TEF 2440 Perimeter Light
- Suitable for Safe Areas
- Green/red LED light
- Rugged construction, low maintenance
- Resistant to vibrations
- Low power consumption
- Instant light
- Integrated breather/drain plug
- Operating temperature: -30 °C … +45 °C
- Operating life: up to 100,000 hours
- IP66 rated
TEF 2460 Perimeter Light
- Suitable for harsh and hazardous areas, onshore and offshore, including Zone 1 or Safe Zone areas
- Green or red/green
- Maintenance-free
- Integrated terminal box with breather/drain plug
- Rugged construction
- Electronics encapsulated to eliminate risk of water ingress
- Instant light
- Resistant to vibrations
- Operating life: 50,000 hours
- IECEx & ATEX approved
Helideck Floodlights
TEF 9975 Helideck Floodlight System
- LED floodlight for Zone 1, Zone 2, Safe Areas and Zones 21 & 22
- Marine grade, anodized aluminium casing
- Integral mounting bracket to allow for easy fixing and beam direction adjustment
- Shock-resistant with clear toughened glass
- Superior light output with Fresnel lens
- Cooling fins and air ducts to dissipate heat
- Operating temperature: -40 °C … +55 °C
- High and low bracket and voltage options available
Helideck Obstruction Lights
TEF 2460 Ex Obstruction Light
- Suitable for Zone 1, Zone 2 and Safe Zone areas
- Low-intensity obstruction light (Type A & B)
- Rugged construction: brass alloy and polycarbonate dome
- Maintenance-free with encapsulated electronics to eliminate water ingress
- Instant light
- Integrated terminal box with drain plug/breather
- Operating temperature: -55 °C ... +55 °C
- Operating life: up to 50,000 hours
TEF 2440 Obstruction Light
- Suitable for Safe Areas
- LED, low-intensity, Type B
- Acid-proof stainless steel construction with polycarbonate globe
- Low maintenance
- Low power consumption
- Vibration resistant
- Operating temperature: -30 °C … +45 °C
- Operating life: up to 50,000 hours
- IP66 rated
Helideck Lights Control Systems (HLCS)
TEF 4500 Commander Utility Dual Power Helideck Control Panel
- Helideck lighting complete control system
- Suited for installation in bridge or radio equipment room
- Enclosure can be located elsewhere with use of cable
- 8 buttons control perimeter, flood and windsock lights
- 3 spare buttons available for added components in enclosure
- Up to 7 control panels can be connected to network for monitoring and control from different locations
- Alarm on circuit breakers
- Automatic failover to emergency power source
TEF 4600 Helideck Control Panel
- Integrated helideck lighting control system
- Suitable for both safe areas and Zone 1 areas, onshore and offshore
- For use with all R. STAHL TRANBERG lights, including perimeter, flood, obstruction, windsock, circle & H and status lights
- User-friendly, pre-programmed touch panel
- Lighting can be set to on, off or dimmed
- Touch panel can be located on door of main panel (safe area) or located elsewhere
- Exicom MT-498 panel is available for Zone 1 or 2 areas
- Simplified connections with one cabinet housing all control gear
- Smaller footprint than multiple individual control cabinets
- Reduces required inspections and maintenance when used in conjunction with new range of R. STAHL TRANBERG helideck lighting
- Options include remote button and lamp control panel, integration with helideck monitoring system (HMS) and SCADA system
- ATEX/IECEx approved
Additional Products
The R. STAHL Tranberg range of products also includes the following:
- Junction & terminal boxes
- Heat tracing solutions
- Cable glands
- Cable cleats
- Enclosure heaters
- Marine lighting
- Complete helideck lighting packages
- Navigation lights systems
- Windsocks
Technical Product Library
Industrial and Hazardous Area Solutions from R. STAHL
Explore MacLean Electrical’s technical library to access up-to-date product information and view the wider R. STAHL range.
About R. STAHL
The Experts in Explosion Protection
With a history that can be tracked back 130 years, R. STAHL is synonymous with the highest quality and demanding solutions. With a strong safety culture, the brand strives to not only comply with safety standards but set new standards of their own.
